Y系列一般壓力表Y60
Y系列一般壓力表Y60的產品介紹（中文）
Y系列一般壓力表Y60是一種廣泛應用于工業領域的壓力測量儀表，適用于測量無爆炸危險、不結晶、不凝固且對銅合金無腐蝕作用的液體、氣體或蒸汽介質的壓力。該產品采用徑向無邊設計，表盤直徑為60毫米，具有結構緊湊、安裝簡便的特點。其測量范圍覆蓋0~0.1MPa至0~60MPa等多種規格，能夠滿足不同工況需求。產品采用彈簧管測量系統，通過機械傳動機構將壓力變化轉換為指針的角位移，實現壓力值的直觀顯示。Y60壓力表的工作環境溫度為-40℃至+70℃，在相對濕度不大于85%的條件下可穩定工作。接頭螺紋采用M14×1.5標準規格，便于現場安裝連接。產品外殼選用優質材料制造，具有良好的防護性能，能夠適應多種工業環境的使用要求。1246
Y Series General Pressure Gauge Y60 Product Introduction (English)
The Y Series General Pressure Gauge Y60 is a widely used industrial instrument designed for measuring pressure of non-explosive, non-crystallizing, non-solidifying liquids, gases or vapors that do not corrode copper alloys. Featuring a compact radial design with a 60mm dial diameter, this pressure gauge offers easy installation and reliable performance. The measurement ranges span from 0~0.1MPa to 0~60MPa, accommodating diverse operational requirements. The gauge utilizes a bourdon tube measurement system that converts pressure variations into angular displacement of the pointer through mechanical transmission mechanisms, providing clear visual indication of pressure values. With an operating temperature range of -40℃ to +70℃ and maximum relative humidity of 85%, the Y60 demonstrates stable performance in various industrial environments. The M14×1.5 threaded connection ensures convenient field installation. The durable housing provides effective protection, making the gauge suitable for multiple industrial applications. The product s simple yet robust design focuses on functionality and measurement accuracy, making it a practical choice for pressure monitoring in different industrial processes.25613
Y系列一般壓力表Y60
深圳大量批發供應SUS304全不銹鋼壓力表ZYIAY60，0.05級 YBSC數顯壓力表 0.1~60Mpa任選批發精密數字壓力表，抗振壓力表耐震壓力表 充油壓力表抗振，供應精密壓力表，專供YB150A150B精密壓力表。數顯數字壓力表計精密壓力表不銹鋼高精度耐震智能液晶數顯壓力表，壓力表 優質不銹鋼耐震壓力表 正德精密不銹鋼壓力表批發YN60ZT，壓力表機芯配件 沖壓配件 機芯五金件，供應01.6MPA YB150 0.4級 精密壓力表，存儲型智能精密數字微壓計DPI 100，數字微壓差計，0.5級微壓表。氣瓶測壓表 呼吸器器瓶 壓力表 碳纖維氣瓶測壓表 G5/8螺紋，日本SMC品帶壓力開關的壓力表GP461001L5 1分口精密壓力表，原裝日本SMC壓力表 G461002G361001G36201 WIKA壓力表，AZ8230精密電子壓差表壓力計數字微壓差計壓力表數顯。精密耐震壓力表高壓油泵專用柳州精密壓力表廣西精密壓力表，臺灣CHELIC PRESSURE GAUGE 壓力錶，壓力表 數字壓力表 精密數字壓力表 電池供電 0.160Mpa定制，數字壓力表可以帶遠傳輸出，微壓表。
