精密壓力表/YB150調試標準表西儀YB150A精表大量定做
產品概述
精密壓力表YB150/YB150A是一款高精度測量?jī)x器，采用優質合金材料制造，適用于工業現場和實驗室環境中的壓力測量與校驗工作。該系列產品以其穩定的性能和清晰的讀數設計，廣泛應用于石油、化工、電力、冶金等行業領域。產品設計采用彈簧管測量系統，確保在多種介質環境下均能提供可靠的數據支持。123
產品特點
YB150A型號在刻度盤下方設有特制鏡面環設計，使指針讀數更加清晰直觀，有效減少視覺誤差。產品采用精密齒輪傳動機構，確保壓力傳導的準確性和穩定性。表殼部分采用防護性設計，能夠有效抵御外部環境對內部測量機構的影響，延長使用壽命。產品提供多種壓力量程選擇，從-0.1MPa至100MPa滿足不同工況需求。458
技術參數
該系列產品精度等級為0.25級和0.4級可選，使用環境溫度為5～40℃，相對濕度不超過80%。產品采用標準M20×1.5螺紋連接方式，公稱直徑150mm。彈簧管材料根據測量范圍不同可選用錫磷青銅或合金結構鋼，確保在各種介質條件下保持穩定的測量性能。溫度影響系數為0.4%/10℃，保證在溫度變化環境下的測量準確性。61013
產品優勢
YB150系列精密壓力表具有結構簡單、維護方便的特點，測量機構經過特殊工藝處理，確保長期使用的穩定性。產品外形美觀大方，鏡面設計配合高精度指針指示，大大提升了讀數的便捷性。我們可根據客戶需求提供不同規格的定制服務，包括特殊量程、特殊接口等個性化需求。嚴格的出廠檢驗制度保證每一臺產品都符合行業技術要求。7911
應用領域
本產品適用于測量對銅合金和合金結構鋼無腐蝕性、非結晶、非凝固的各種介質的壓力，是工業生產過程控制、設備維護和實驗室研究的重要工具。特別適合用于校驗普通工業壓力表，也可作為精密測量?jī)x表使用。產品被廣泛應用于機械制造、能源化工、食品制藥等行業的生產監測和質量控制環節。121416
Product Introduction
The YB150/YB150A precision pressure gauge is a high-accuracy measuring instrument manufactured with premium alloy materials. Suitable for both industrial sites and laboratory environments, this product series ensures reliable pressure measurement and calibration with its stable performance and clear reading design. The gauges are widely used in petroleum, chemical, power generation, metallurgy and other industrial fields. 171819
Key Features
The YB150A model features a specially designed mirror ring beneath the dial, providing clearer pointer readings and effectively reducing visual errors. Equipped with precision gear transmission mechanisms, it guarantees accurate and stable pressure measurement. The protective casing design effectively shields the internal measuring mechanism from external environmental impacts, extending service life. Multiple pressure ranges are available from -0.1MPa to 100MPa to meet various working condition requirements. 202223
Technical Specifications
This product series offers optional accuracy classes of 0.25 and 0.4 grade, operating in environments with temperatures between 5～40℃ and relative humidity below 80%. Standard M20×1.5 threaded connection is adopted with nominal diameter of 150mm. Different spring tube materials including tin phosphor bronze and alloy structural steel are used according to measurement ranges, ensuring stable performance under various media conditions. Temperature coefficient of 0.4%/10℃ guarantees measurement accuracy in changing temperature environments. 242526
Product Advantages
The YB150 series features simple structure and easy maintenance, with measuring mechanism specially treated to ensure long-term stability. Elegant appearance combined with mirror design and high-precision pointer indicator significantly improves reading convenience. Customized services including special ranges and connections are available according to customer requirements. Strict factory inspection procedures ensure every product meets industry technical requirements. 272829
Application Fields
These gauges are suitable for measuring pressure of various media that are non-corrosive to copper alloy and alloy structural steel, non-crystalline and non-solidifying. They serve as essential tools for industrial process control, equipment maintenance and laboratory research. Particularly suitable for calibrating ordinary industrial pressure gauges or serving as precision measuring instruments, the products are widely applied in production monitoring and quality control in machinery manufacturing, energy & chemical, food & pharmaceutical industries. 30
