聲光報警器BC-600M
產品概述
BC-600M大功率聲光報警器是一款專為工業環境設計的警示設備，采用聲光同步示警方式，適用于起重機械、港口碼頭、冶金礦山等大型設備的安全報警。其外殼采用噴塑鋼板和PS材質雙層燈罩，兼具防塵、防水及抗沖擊性能，適合露天或惡劣工況使用。內置50W大功率喇叭和高亮度LED燈組，聲音傳播距離遠，光警示效果醒目，可有效提醒現場人員注意安全。1829
核心功能
該產品支持USB在線錄制語音，用戶可自行更換MP3或WAV格式的音頻文件，靈活適配不同場景的語音提示需求。提供8種可選音調（如警笛音、工程音等），音量可調至130分貝，確保在嘈雜環境中清晰可聞。LED燈采用爆閃模式，配合科學散光設計，增強視覺警示效果。三層腔體分層結構使喇叭、主控板與燈控板獨立工作，提升了穩定性和耐用性。1830
技術特點
BC-600M工作電壓覆蓋DC12V至AC380V（可定制），適應多種電氣環境。工作溫度范圍-30℃至+70℃，滿足極端氣候條件。產品重量輕，安裝簡便，支持壁掛或固定安裝。其防震設計和全金屬外殼有效抵御機械沖擊與電磁干擾，適合長期連續運行。用戶可根據實際需求選擇不同音調和燈光顏色（紅、黃、藍等），實現個性化警示方案。1828
應用場景
廣泛應用于鋼鐵冶金、遠洋船舶、風力發電等領域，尤其適用于天車、橋吊等高空作業設備的移動預警，或輸送帶、礦場等需要遠距離警示的場所。通過聲光聯動，顯著提升作業區域的安全管理效率。630
Product Overview
The BC-600M high-power audible and visual alarm is designed for industrial environments, combining loud audio alerts with bright flashing lights to enhance safety in heavy-duty applications such as cranes, ports, and mining operations. Its robust construction features a spray-coated steel shell and double-layer PS lamp cover, ensuring resistance to dust, water, and physical impacts. Equipped with a 50W speaker and high-intensity LED arrays, it delivers long-range audible signals and highly visible light warnings.1829
Key Features
This alarm supports USB-based voice recording, allowing users to upload custom MP3 or WAV files for tailored alerts. It offers 8 selectable tones (e.g., sirens, industrial tones) with adjustable volume up to 130dB, ensuring clarity in noisy settings. The strobe-like LED flashes are optimized for maximum visibility through a scientifically designed diffuser. Its three-chamber architecture isolates the speaker, control board, and lighting modules, improving reliability.1830
Technical Specifications
The BC-600M operates across a wide voltage range (DC12V to AC380V, customizable) and withstands temperatures from -30°C to +70°C. Lightweight and easy to install, it supports wall-mounting or fixed placement. Anti-vibration design and electromagnetic interference shielding ensure consistent performance in harsh conditions. Users can choose from multiple light colors (red, yellow, blue, etc.) and tones to match specific operational needs.1828
Applications
Ideal for steel plants, offshore vessels, and wind farms, this alarm excels in scenarios requiring long-distance warnings, such as overhead crane movements or conveyor belt operations. Its synchronized audio-visual alerts significantly enhance on-site safety management.630
聲光報警器BC-600M聲光報警器BC-600M
產品簡介：
大型起重機械等行走設備在冶金企業中是非常重要的設備，它露天作業使用頻繁、啟動聲音小、速度較快，容易因不被現場人員注意而發生**事故。我廠生產的TBJ-150一體化聲光報警器，是針對大型起重機械的工作特點和結構特性而開發的專用報警器，具有許多專業化的特點。
產品特點：
·5W、25W報警音響——聲音宏亮
·帶不銹鋼防護罩旋轉警燈——高亮度、耐沖擊
·防風雨電路工藝設計——防水、防塵、質量可靠
·警燈、警號一體化——安裝簡便
·交流220V觸發即報警——操作簡單
·可選擇高亮度LED頻閃燈——高質量、壽命長、高亮度
技術參數：
BC-600M
|
工作電壓
AC220V、50Hz
|
警號功率
5W、25W
|
警燈直徑
D=150mm
|
|
防護罩
不銹鋼
|
觸發信號
AC220V
|
殼體材料
鋼板、噴涂
|
|
外形尺寸（高x長x寬）：435x180x155（mm）
|
BC-600M
|
工作電壓
AC220V、50Hz
|
警號功率
5W、25W
|
警燈直徑
D=150mm
|
|
防護罩
不銹鋼
|
觸發信號
AC220V
|
殼體材料
鋼板、噴涂
|
|
外形尺寸（高x長x寬）：435x180x155（mm）
|
