BC-2C聲光報警器
BC-2C聲光報警器產品介紹（中文）
BC-2C多用途聲光報警器是專為港口起重機械、冶金及機電行業大型行車設計的工業級安全警示設備。該產品采用模塊化設計，具有體積小巧、外觀新穎、操作簡便等特點，可提供多種音調報警模式，包括A/B/E三種基礎音調，并支持根據用戶需求定制特殊音效或語音內容。設備配備25W功率喇叭（阻抗16Ω）的雙喇叭系統，聲壓級可達106-110dB，確保在嘈雜工業環境中清晰傳遞警示信號�？刂葡渲С致暪馔綀�(bào)警功能，可選配手持話筒或鵝頸話筒實現喊話廣播，延時報警功能可在5-20秒間連續調節。外殼采用耐腐蝕材質，具有良好的防水防塵性能，適用于行車、橋吊、汽車吊等設備的司機室安裝，能有效協調作業流程并提升現場安全性。2411
BC-2C Multifunctional Audible & Visual Alarm (English)
The BC-2C multifunctional alarm system is engineered for heavy-duty industrial applications including port cranes, metallurgical facilities and large-scale conveying equipment. Featuring a compact control unit with dual 25W speakers (16Ω impedance), it delivers 106-110dB output with selectable A/B/E alarm tones, while offering optional voice message customization. The device integrates synchronized flashing LED lights and microphone input (handheld/gooseneck type available), with adjustable delay timer ranging 5-20 seconds. Its corrosion-resistant housing provides IP-rated protection against dust and moisture, suitable for installation in cab-operated machinery like overhead cranes and gantry lifts. The intuitive interface allows flexible configuration of audio-visual alert patterns to enhance worksite coordination and personnel safety in demanding environments. 5815
核心功能特點
該設備支持音量連續調節和多種組合工作模式，系統包含控制箱、雙喇叭及話筒組件，可通過不同音調組合實現設備狀態區分報警。示警燈采用高亮度LED光源，壽命超過10萬小時，燈罩選用抗沖擊PC材料。工作電壓兼容AC24V-380V或DC24V-48V，電源頻率50-60Hz，適應各類工業用電環境。特殊設計的抗干擾電路確保在強電磁場中穩定運行，廣泛應用于工程機械、物流輸送等需要多重安全警示的場合。3626
Technical Specifications
Operating at 50-60Hz power frequency with wide voltage compatibility (AC24V-380V/DC24V-48V), the unit maintains stable performance under electromagnetic interference. The LED strobe light utilizes polycarbonate lens and achieves over 100,000-hour lifespan. Modular components include main control box, twin 25W/16Ω speakers and detachable microphone, supporting mixed tone alerts for multi-status indication. Typical applications cover material handling systems, mobile cranes and workshop safety monitoring where customizable audible-visual signals are required. The humanized design emphasizes ease of maintenance and durability in harsh operating conditions. 91222
BC-2C聲光報警器聲光報警器BC-2C
產品簡介：
大型起重機械等行走設備在冶金企業中是非常重要的設備，它露天作業使用頻繁、啟動聲音小、速度較快，容易因不被現場人員注意而發生**事故。我廠生產的TBJ-150一體化聲光報警器，是針對大型起重機械的工作特點和結構特性而開發的專用報警器，具有許多專業化的特點。
產品特點：
·5W、25W報警音響——聲音宏亮
·帶不銹鋼防護罩旋轉警燈——高亮度、耐沖擊
·防風雨電路工藝設計——防水、防塵、質量可靠
·警燈、警號一體化——安裝簡便
·交流220V觸發即報警——操作簡單
·可選擇高亮度LED頻閃燈——高質量、壽命長、高亮度
技術參數：
BC-2C
|
工作電壓
AC220V、50Hz
|
警號功率
5W、25W
|
警燈直徑
D=150mm
|
|
防護罩
不銹鋼
|
觸發信號
AC220V
|
殼體材料
鋼板、噴涂
|
|
外形尺寸（高x長x寬）：435x180x155（mm）
|
BC-2C
|
工作電壓
AC220V、50Hz
|
警號功率
5W、25W
|
警燈直徑
D=150mm
|
|
防護罩
不銹鋼
|
觸發信號
AC220V
|
殼體材料
鋼板、噴涂
|
|
外形尺寸（高x長x寬）：435x180x155（mm）
|
