BC-2F聲光報警器SYD220D-1，SYD220D-2，SYD220D-3，SOA-400A，SAK125D，TBD-360
BC-2F多用途聲光報警器
BC-2F多功能設備報警器是針對港口起重機械、冶金機電行業大型行車工況研發的聲光同步警示裝置。該產品采用鋁合金翻砂鑄造外殼，結構美觀且具備優異的防水防塵性能（防護等級IP65），內置集成電路確�？垢蓴_能力與工作穩定性。提供A/B/E三種可調音調，配備25W/16Ω喇叭和鵝頸話筒，適用于工程機械、港口設備等場景的安全預警。旋轉警燈采用LED光源，壽命超10萬小時，PC材質燈罩具有抗沖擊特性。11518
The BC-2F multi-purpose audible and visual alarm is designed for large-scale industrial equipment such as port cranes and metallurgical machinery. Its cast aluminum alloy housing features corrosion resistance and IP65-rated sealing, while the integrated circuit ensures reliable operation. With selectable A/B/E alarm tones and a 25W/16Ω speaker, this device provides effective warning signals in harsh environments. The rotating beacon utilizes long-life LED tubes and impact-resistant PC covers.
SYD220D系列船用電子報警器
SYD220D系列是專為船舶環境設計的電子聲光報警系統，包含SYD220D-1/2/3三種型號。產品采用低碳鋼板噴塑外殼與合金揚聲器組件，支持220V交流供電，聲壓級達106dB以上。閃光燈采用無燈絲氣體放電管，支持連續頻閃模式，適用于船艙走道、輪機艙等區域的緊急警示。該系列通過特殊結構實現防鹽霧腐蝕和抗震功能，可定制語音報警內容。51930
The SYD220D series marine electronic alarms consist of SYD220D-1/2/3 models with weatherproof steel enclosures and alloy speakers. Operating at 220V AC with over 106dB output, these devices employ gas-discharge flash tubes for high-intensity visual alerts. Designed for shipboard environments, they feature anti-corrosion construction and customizable voice prompts, suitable for engine rooms and passageways.
SOA-400A工業聲光報警裝置
SOA-400A是一款集成式聲光報警設備，采用氙氣頻閃燈與壓電揚聲器組合，工作電壓覆蓋AC220V。產品支持壁掛與法蘭安裝方式，防護等級達IP65，可在-30℃~70℃環境下穩定運行。LED版本提供紅/黃/綠三色可選，閃爍頻率可定制，主要應用于高速公路、地下隧道等需要高強度警示的場所。242526
The SOA-400A industrial alarm combines xenon strobe lights with piezoelectric speakers, compatible with 220V AC power supply. Available in wall-mount and flange versions, it operates reliably within -30℃~70℃ range (IP65 rated). The LED variant offers red/yellow/green color options with adjustable flash patterns, ideal for highway and tunnel safety applications.
SAK125D與TBD-360安全警示器
SAK125D聲光報警器采用尼龍-GF30%復合材料主體，支持AC/DC寬電壓輸入，功率10W時聲壓可達108dB。TBD-360型號則配備50W大功率喇叭和防爆結構，適用于礦山、油田等極端環境。兩款產品均具有音量可調和報警延時功能，燈罩采用抗UV老化PC材料，確保長期戶外使用的可靠性。162027
The SAK125D alarm features nylon-GF30% composite housing with wide voltage input range, delivering 108dB at 10W power. The TBD-360 model incorporates 50W speakers and explosion-proof construction for mining/oilfield applications. Both devices include volume adjustment, delay functions, and UV-resistant PC covers for durable outdoor performance.
BC-2F聲光報警器聲光報警器BC-2F
產品簡介：
大型起重機械等行走設備在冶金企業中是非常重要的設備，它露天作業使用頻繁、啟動聲音小、速度較快，容易因不被現場人員注意而發生**事故。我廠生產的TBJ-150一體化聲光報警器，是針對大型起重機械的工作特點和結構特性而開發的專用報警器，具有許多專業化的特點。
產品特點：
·5W、25W報警音響——聲音宏亮
·帶不銹鋼防護罩旋轉警燈——高亮度、耐沖擊
·防風雨電路工藝設計——防水、防塵、質量可靠
·警燈、警號一體化——安裝簡便
·交流220V觸發即報警——操作簡單
·可選擇高亮度LED頻閃燈——高質量、壽命長、高亮度
技術參數：
BC-2F
|
工作電壓
AC220V、50Hz
|
警號功率
5W、25W
|
警燈直徑
D=150mm
|
|
防護罩
不銹鋼
|
觸發信號
AC220V
|
殼體材料
鋼板、噴涂
|
|
外形尺寸（高x長x寬）：435x180x155（mm）
|
BC-2F
|
工作電壓
AC220V、50Hz
|
警號功率
5W、25W
|
警燈直徑
D=150mm
|
|
防護罩
不銹鋼
|
觸發信號
AC220V
|
殼體材料
鋼板、噴涂
|
|
外形尺寸（高x長x寬）：435x180x155（mm）
|
